The world's first mass-produced 8-in-1 electric powertrain
BYD has an exceptional vertical integration capabilities within the supply chain. BYD integrates 8 key components incorporating VCU, BMS, MCU, PDU, DC-DC controller, on-board charger, drive motor and transmission, producing the world’s first mass-produced 8-in-1 electric powertrain system, greatly optimising space utilisation and energy efficiency.
High efficiency heat pump system as standard
An advanced energy-saving heat pump system comes as standard. Reliably operating in a broad range of temperatures, the system is designed to highly utilise residual heat from surroundings, the powertrain, passenger compartment and even the batteries. It enhances the thermal efficiency and reduces energy loss whether heating or cooling. Therefore, the low-temperature driving range is increased.
Prepare to be impressed
The BYD ATTO 3 equipped with 150kW motor, accelerates from 0-62mph in just 7.3 seconds.
Driving Performance
Electric motor type
| Permanent Magnet Synchronous Motor
|
Drive mode
| FWD
|
Max. power (kW/PS), rpm
| 150/204, 5000-8000
|
Max. torque (lb ft/N·m), rpm
| 228/310, 0-4620
|
Acceleration 0-100 km/h (s)
| 7.3 |
Top speed (km/h)
| 160
|
Drag coefficient (Cd)
| 0.29 |
Front suspension
| MacPherson suspension
|
Rear suspension
| Multi-link suspension
|
Brakes
| Ventilated disc brakes
|
Battery
Battery type
| BYD Blade Battery (LFP)
|
Battery capacity (kWh)
| 60.48
|
Battery position
| Under floor
|
Nominal voltage (V)
| 403.2
|
Capacity (Ah)
| 150
|
Battery weight (kg)
| 420 (±3%)
|
Energy density (Wh/kg)
| 140 |
WLTP Consumption
Electric range - combined (km)
| 420 |
Electric range - city (km)
| 565 |
Consumption-combined-kwh/100km | 15.6 |
Consumption - city - miles/kWh (Wh/km)
| 12.0 |
CO 2 Emissions - combined (g/km)
| 0 |
